Place of Origin:
Chongqing, China
Brand Name:
TAIWO
Certification:
ISO9001
Model Number:
TAIWO-TYJ-002
Contact Us
Blade Type Friction Plate Type 260mm Gasoline Direct Transmission Mode 4.0KW Small Garden Tiller
Description
Use specifications and precautions
When the Small Garden Tiller is running, people are strictly prohibited to approach the rotating parts, and no one behind the Small Garden Tiller is allowed, it is to prevent the rotary cutter from throwing out and hurting people.
When inspecting the Small Garden Tiller, the power must be cut off first.
When replacing rotating parts such as rotary cutter, the machine must be turned off.
When plowing, the advancing speed should be 2 to 3 kilometers per hour in dry fields, and 5 to 7 kilometers per hour in plowed or rake fields. Plowing fields can be made faster.
The speed cannot be too high, to prevent the engine from overloading and damaging the PTO shaft.
Specification
| Item | Specification |
| Structure Type | Double Shaft, Wheel Type |
| Work Size | 1740mm*760mm*900mm |
| Net Weight | 112KG |
| Engine Model | 170F |
| Power Type | Gasoline |
| Rated Power | 4.0KW 3600rpm |
| Transmission Mode | Direct |
| Working Width | 260mm |
Advantage
1. Standard functions: ditching, earth-raising, wasteland clearing, weeding, ridging
2. Optional functions: more than 40 kinds of functions, such as medicine, sowing, fertilization, rotary tillage, soil loosening, medium tillage, deep tillage, weeding, spraying insecticide, harvesting, spreading film, pumping water and pouring.
3. Suitable for soil: it is widely used in plain clay land, hard rock land in mountainous area, dry land of hilly hill, etc., and special soil paddy field and swamp, please call to buy special models.
4. The new handle is a lever design: advantages, more flexible and convenient operation.
5. Unique features of multi-functional garden management machine
Ditch effect is good: depth up to 30 cm, width between 15 cm to 40 cm, change the tool, depth and width flexible adjustment, easy operation, simple and practical.
Durable: thickened body, chain and gear drive, cutlery are 75 manganese steel forged, very wear-resistant, durable and economical.
6. Mini tiller cultivator can be equipped with many kinds of engine in line with national environmental protection requirements, such as 170F, 173F, 178F, 186F, etc;
7. Using front drive and back rotary tillage, easier operation;
8. Mini tiller cultivator is suitable for orchard, greenhouse operation.
